Patterns in confusing explanations

4 Shares

Hello! Recently I’ve been thinking about why I explain things the way I do. The usual way I write is:

  1. Try to learn a topic
  2. Read a bunch of explanations that I find confusing
  3. Eventually understand the topic
  4. Write an explanation that makes sense to me, to help others

So why do I find all these explanations so confusing? I decided to try and find out! I came up with a list of 13 patterns that make explanations hard for me to understand. For each pattern I’ll also explain what I like to do instead to avoid the issue.

these patterns are very normal

This list isn’t meant to make you feel bad about your writing. I’ve probably done all of these things! I’m certainly going to do them again! I even did at least one of them while writing this post!

But knowing that I’m likely to accidentally do these things makes it easier for me to avoid them, and it makes me more receptive to critique when people point out issues with my writing (“Julia, this is assuming a lot of knowledge that I don’t have!“).

Being aware of these patterns also helps me when reading a confusing explanation: “oh, I’m not confused by this explanation because I’m stupid, I’m confused because it’s introduced 6 new-to-me concepts and it hasn’t explained what any of them is yet!“.

why this post is framed in a negative way

I practically always write in a positive way (“X is a good practice!”) instead of in a negative way (“Y is a bad practice!”). So why am I writing about confusing patterns instead of writing about positive patterns?

Writing clearly is a LOT of work. A big part of what motivates me to put in the work to write clearly is my frustration with confusing technical explanations (“ugh, everything I read about Linux containers was SO confusing, I wish someone had just told me X Y Z…“).

But, if I’m not careful, it’s easy to reproduce the exact same confusing patterns in my own writing! And the problem with positive patterns (like “avoid introducing unnecessary jargon”) is that they seem so obvious that I trick myself into thinking I’m following them, even when I’m not! So I’m writing these down to try to keep myself honest and hopefully help you avoid some of these patterns as well.

now for the patterns!

Now that I’ve explained my motivation, let’s explain the patterns! Here’s a quick index of all of them. They’re not in any particular order.

  1. pattern 1: making outdated assumptions about the audience’s knowledge
  2. pattern 2: having inconsistent expectations of the reader’s knowledge
  3. pattern 3: strained analogies
  4. pattern 4: fun illustrations on dry explanations
  5. pattern 5: unrealistic examples
  6. pattern 6: jargon that doesn’t mean anything
  7. pattern 7: missing key information
  8. pattern 8: introducing too many concepts at a time
  9. pattern 9: starting out abstract
  10. pattern 10: unsupported statements
  11. pattern 11: no examples
  12. pattern 12: explaining the “wrong” way to do something without saying it’s wrong
  13. pattern 13: “what” without “why”

pattern 1: making outdated assumptions about the audience’s knowledge

I see a lot of writing, especially systems writing, that makes outdated assumptions about what the reader knows. For example, here’s a paragraph from this Git book comparing Git’s implementation of branching to other version control tools.

Nearly every VCS has some form of branching support. […] In many VCS tools, this is a somewhat expensive process, often requiring you to create a new copy of your source code directory, which can take a long time for large projects.

The outdated assumption here is that you (the reader) know how other version control systems implement branching, and that comparing other tools’ implementation of branching to Git’s implementation will help you understand branching.

But if you’re reading this and you’ve never used another version control system and never plan to, this explanation is useless! Who cares about how other version control systems implement branching? You just want to understand how Git works!

The reason this explanation is written this way is probably that the first edition of the book was published in 2009, and this assumption was probably true in 2009! Many people learning Git shortly after it was released were switching from Subversion or CVS or something and found comparisons like this helpful.

But in 2021 Git has been the dominant version control system for a long time, and most people learning Git for the first time won’t have any experience with version control other than Git.

I also sometimes see this “outdated assumptions about the audience’s knowledge” problem with newer writing. It generally happens when the writer learned the concept many years ago, but doesn’t have a lot of experience explaining it in the present. So they give the type of explanation that assumes that the reader knows approximately the same things they and their friends knew in 2005 and don’t realize that most people learning it today have a different set of knowledge.

instead: test your explanations!

Usually if I learned a concept a long time ago, it means that I’ve lost touch with what it’s like to learn it for the first time today. So running an explanation by a few people who don’t already know the concept helps to catch incorrect assumptions I’ve made.

(I bolded “don’t already know the concept” because it’s tempting to ask someone who already understands the concept for a review. But they might have the exact same blind spots as you!)

pattern 2: having inconsistent expectations of the reader’s knowledge

For example, a new language tutorial might explain a concept that almost all programmers would know, like how a for loop is used for iteration, while the writing that immediately follows implicitly assumes knowledge that many people don’t have, like how the stack works, how malloc works, etc. (thanks to Dan Luu for this example!)

The problem with this is that are probably zero people who understand malloc but don’t understand how a for loop works! And even though it sounds silly, it’s easy to accidentally write like this if you don’t have a clear idea of who you’re writing for.

instead: pick 1 specific person and write for them!

You can pick a friend, a coworker, or just a past version of yourself. Writing for just 1 person might feel insufficiently general (“what about all the other people??“) but writing that’s easy to understand for 1 person (other than you!) has a good chance of being easy to understand for many other people as well.

pattern 3: strained analogies

Sometimes when trying to explain a complex technical concept, an author will start with a real-world concept that the reader definitely understands and use a very involved analogy to compare them.

Here’s an example I made up:

Imagine our event system is like the Mississippi River. It travels through many different ecosystems, and some rain particles don’t make it all the way. Sometimes it flows at different speeds depending on environmental conditions. The Mississippi River ends in many different tributaries.

Many different kinds of fish live in the event system. Different fish have different destinations. Humans decide to live along the river and use it for different purposes. They construct dams to control the flow.

This example is a parody, but I always find this type of analogy confusing because I end up wasting a lot of time trying to analyze exactly how an event stream is different / the same as the Mississippi river instead of just learning technical facts about event streams:

I think authors do this because.. it’s kind of fun to write these Big Weird Analogies! Like, is there something in a stream processing system that’s like a dam? Maybe! It’s kind of fun to think about! But even though these can be fun to write, they’re not as fun to read – it’s a struggle to extract the actual technical facts you want to know.

instead: keep analogies to a single idea

Instead of using “big” analogies where I explain in depth exactly how an event processing system is like a river, I prefer to explain the analogy in one or two sentences to make a specific point and then leave the analogy behind.

Here are 2 ways to do that.

option 1: use “implicit” metaphors

For example, if we’re talking about streams, I might write:

Every event in a stream flows from a producer to a consumer.

Here I’m using the word “flow”, which is definitely a water metaphor. I think this is great – it’s an efficient way to evoke an idea of directionality and the idea that there are potentially a large number of events.

I put together a bunch more metaphors in this style in Metaphors in man pages.

option 2: use a very limited analogy

For example, here’s a nice explanation from When costs are nonlinear, keep it small by Jessica Kerr that explains batching using an analogy to doing your laundry in a batch.

We like batching. Batching is more efficient: doing ten at once is faster than doing one, one, two, one, one, etc. I don't wash my socks as soon as I take them off, because lumping them in with the next load is free.

This analogy is very clear! I think it works well because batching in laundry works for the same reasons as batching in computing – batching your laundry works because there’s a low incremental cost to adding another pair of socks to the load. And it’s only used to illustrate one idea – that batching is a good choice when there’s a low incremental cost for adding a new item.

pattern 4: fun illustrations on dry explanations

Sometimes I see authors put fun illustrations with a very dry explanation to make the explanation seem more appealing and approachable.

The goal isn’t generally to trick the reader into expecting a more friendly explanation – I think the logic is usually more like “people like fun illustrations! let’s add some!“. But no matter what the intent, the problem is that the reader can end up feeling misled.

instead: make the design reflect the style of the explanation

There are lots of great examples of illustrated explanations where the writing is in a clear and friendly style:

On the other hand, dry explanations are useful too! Nobody expects the Intel instruction-set reference to be light reading! The writing is dry and technical, and the design is very utilitarian, which matches the style of the writing.

pattern 5: unrealistic examples

Here’s an unrealistic example of how to use lambda in Python:

numbers = [1, 2, 3, 4]
squares = map(lambda x: x * x, numbers)

This example is unrealistic because most people don’t use map in Python – you’d use list comprehensions to do this instead.

Here’s another unrealistic example: an interface example from the Oracle docs on interfaces.

interface Bicycle {
    //  wheel revolutions per minute
    void changeCadence(int newValue);
    void changeGear(int newValue);
    void speedUp(int increment);
    void applyBrakes(int decrement);
}

This kind of “real world example” is super common in object oriented programming explanations but I find it quite confusing – I’ve never implemented a bicycle or car in my code! It doesn’t tell me anything about what interfaces are useful for!

instead: write realistic examples!

Here’s a more realistic example of Python lambdas, which sorts a list of children by their age. (from my post Write good examples by starting with real code) This is how I use Python lambdas the most in practice.

children = [
    {"name": "ashwin", "age": 12},
    {"name": "radhika", "age": 3},
]
sorted_children = sorted(children, key=lambda x: x['age'])

Here’s a more realistic example of Java interfaces.

The Comparable interface (from the JDK source) just has one method -- here's its full implementation.

public interface Comparable<T> {
    int compareTo(T o);
}

To implement this interface, you just need to implement the compareTo method. And if you write a class that implements this interface (like a Money class for example), then you get all sorts of useful things for free! You can sort an array of Money objects with Arrays.sort! You can put them in a SortedSet!

In this Java example, of course it’s not enough to explain built-in Java interfaces – you also need realistic examples of how to create and use your own interfaces. But this post isn’t about Java interfaces so let’s move on.

pattern 6: jargon that doesn’t mean anything

Let’s talk about this sentence from this chapter on commit signing:

Git is cryptographically secure, but it’s not foolproof.

“Cryptographically secure” is unclear here because it sounds like it should have a specific technical meaning, but it’s not explained anywhere what’s actualy meant. Is it saying that Git uses SHA-1 to hash commits and it’s difficult to generate SHA-1 hash collisions? I don’t know!

Using jargon in a meaningless way like this is confusing because it can trick the reader into thinking something specific is being said, when the information they need is not actually there. (the chapter doesn’t explain anywhere what’s meant by “cryptographically secure” in this context)

instead: Avoid jargon where it’s not needed

A lot of the time I find I can communicate what I need to without using any jargon at all! For example, I’d explain why commit signing is important like this:

When making a Git commit, you can set any name and email you want! For example, I can make a commit right now saying I'm Linus Torvalds like this:
git commit -m"Very Serious Kernel Update" \
 --author='Linus Torvalds <torvalds@linux-foundation.org>'


pattern 7: missing key information

Sometimes explanations of a concept are missing the most important idea to understand the concept. For example, take this explanation from this chapter on the Git object model (which by the way has a nice concrete example of how to explore Git’s object model):

Git is a content-addressable filesystem. Great. What does that mean? It means that at the core of Git is a simple key-value data store. What this means is that you can insert any kind of content into a Git repository, for which Git will hand you back a unique key you can use later to retrieve that content.

This paragraph is missing what to me is the main idea of content-addressable storage – that the key for a piece of content is a deterministic function of the content, usually a hash (though the page does later say that Git uses a SHA-1 hash). It’s important that the key is a function of the content and not just any random unique key because the idea is that the content is addressed by itself – if the content changes, then its key also has to change.

This pattern is hard to recognize as a reader because – how are you supposed to recognize that there’s a key idea missing when you don’t know what the key ideas are? So this is a case where a reviewer who understands the subject well can be really helpful.

pattern 8: introducing too many concepts at a time

Here’s an explanation of linkers from this page that I find confusing:

During the link process, the linker will pick up all the object modules specified on the command line, add some system-specific startup code in front and try to resolve all external references in the object module with external definitions in other object files (object files can be specified directly on the command line or may implicitly be added through libraries). It will then assign load addresses for the object files, that is, it specifies where the code and data will end up in the address space of the finished program. Once it’s got the load addresses, it can replace all the symbolic addresses in the object code with “real”, numerical addresses in the target’s address space. The program is ready to be executed now.

Here are the concepts in this paragraph:

  • object modules (.o files)
  • external references
  • symbolic addresses
  • load addresses
  • system-specific startup code

It’s too much!

instead: give each concept some space to breathe

For example, I might explain “external references” like this:

if you run objdump -d myfile.o on an object file you can see that the call function calls are missing a target address, so that's why the linker needs to fill that in.

  33:   e8 00 00 00 00          call   38
           ^^^^^^^^^^^
             this address is all 0s -- it needs to be filled in by the linker!
             with the actual function that's going to be called!
  38:   84 c0                   test   %al,%al
  3a:   74 3b                   je     77
  3c:   48 83 7d f8 00          cmpq   $0x0,-0x8(%rbp)


There’s still a lot of missing information here (how does the linker know what address to fill in?), but it’s a clear starting point and gives you questions to ask.

pattern 9: starting out abstract

Imagine I try to explain to you what a Unix signal using the definition from Wikipedia.

Signals are a limited form of inter-process communication (IPC), typically used in Unix, Unix-like, and other POSIX-compliant operating systems. A signal is an asynchronous notification sent to a process or to a specific thread within the same process to notify it of an event. Signals originated in 1970s Bell Labs Unix and were later specified in the POSIX standard.

By itself, this probably isn’t going to help you understand signals if you’ve never heard of them before! It’s very abstract and jargon-heavy (“asynchonous notification”, “inter-process communication”) and doesn’t have any information about what Unix signals are used for in practice.

Of course, the Wikipedia explanation isn’t “bad” exactly – it’s probably written like that because teaching people about signals for the first time isn’t really the goal of the Wikipedia article on signals.

instead: start out concrete

For example, I wrote this page explaining signals a few years ago.

I start out by relating signals to the reader’s experience (“have you used kill? you’ve used signals!“) before explaining how they work.

pattern 10: unsupported statements

Here’s an explanation of C header files, from this page.

In modern C, header files are crucial tools that must be designed and used correctly. They allow the compiler to cross-check independently compiled parts of a program.

Headers declare types, functions, macros etc that are needed by the consumers of a set of facilities. All the code that uses any of those facilities includes the header. All the code that defines those facilities includes the header. This allows the compiler to check that the uses and definitions match.

This says “In modern C, header files are crucial tools…” (which is true), but it doesn’t explain why header files are crucial. This of course wouldn’t be a problem if the audience already understood why header files in C are important (it’s a very fundamental concept!). But the whole point here is to explain header files, so it needs to be explained.

instead: Prove that your statements are true!

For example, I might write:

Almost every C program includes header files. For example, if you've ever written #include <stdio.h> at the beginning of a C program, stdio.h is a header file. #include basically tells the C preprocessor to paste the contents of stdio.h at the beginning of the program.

One reason header files are important is that they define types and constants you need in your programs. For example, this code by itself will fail to compile with the error error: unknown type name 'FILE', because the FILE type is undefined.

int main() {
    FILE *fp;
    fp  = fopen("data.txt", "w");
}

FILE is defined in stdio.h and if you add a #include <stdio.h>, at the top, then the program will compile.

This example program lets the reader actually run that program themselves and verify that it doesn’t compile if they want – they don’t have to take my word for it!

pattern 11: no examples

Another problem with the previous explanation of header files is – there aren’t any examples! Leaving out examples makes it harder for the reader to relate the new terminology to their own experiences.

Almost anyone who’s ever written a C program has definitely used header files, so a simple example (like mentioning stdio.h) can really help.

In that header files example, I replaced

In modern C, header files are crucial tools…

with an explanation that includes a simple example:

Almost every C program includes header files -- if you've ever seen something like #include at the beginning of a C program, stdio.h is a header file.

pattern 12: explaining the “wrong” way to do something without saying it’s wrong

Here’s a pattern I see sometimes in tutorials (though unfortunately I don’t have an example):

  1. Explain the “wrong” way of doing something without saying up front that it’s wrong
  2. Later on, show the consequences of doing the “wrong” thing
  3. Explain the “right” way

I think the intention of this is to imitate the real-life experience of making mistakes. Usually when you make a mistake, you don’t know that it’s wrong at the time!

But often the reader will end up feeling misled or confused about which way is actually “correct”. And it’s possible that they would never even have made that particular mistake on their own!

instead: here are four options for presenting mistakes

Here are a few ways of accomplishing the same thing without misleading the reader:

  1. Frame the “wrong” thing as an experiment (“what if we try doing it X way?”)
  2. State an incorrect belief the reader might have: (“You might think that the command line tool would need to run as root (because it’s talking to the kernel, but…“)
  3. Explain a common mistake (for example “Avoid Striding and Slicing in a Single Expression” in Effective Python)
  4. Tell a story about a mistake you made and why it caused problems (here’s one of mine: Why Ruby’s Timeout is dangerous (and Thread.raise is terrifying))

Talking about mistakes is very important, just say up front that the thing is a mistake!

pattern 13: “what” without “why”

I very often see people introduce new technologies with a list of features instead of explaining why people choose the technology.

For example, the kubernetes homepage lists a bunch of Kubernetes’ features: automated rollouts and rollbacks, service discovery and load balancing, storage orchestration, secret and configuration management, automatic bin packing, etc. This kind of feature list is pretty common on a project homepage, but by itself it doesn’t help someone understand whether Kubernetes is right for them.

I think one reason writers leave out the “why” is that it’s hard to write a simple universal answer to “why do people use Kubernetes?”. There are a lot of reasons! And if you get the “why” wrong, it’s very noticeable and it feels embarrassing. So it feels safer to just list some features and move on.

But as a reader, I find that a weak “why” is much better than no “why”. I’d rather read “well, we use Kubernetes because it provides a decent basic deployment system and GKE means we don’t have to think about servers” than an attempt at covering every single company’s business reasons for using Kubernetes.

instead: talk about your reasons for using the technology

Of course, if you have a clear universal explanation of the problems a technology solves, that’s great. But I think a lot of the time authors (including me!!) just don’t have a great grasp of why other people are choosing a given technology. That’s okay!

If you don’t feel you can give a universal “why”, I think it’s better to just be open about that and give an example from your personal experience.

For example, I might say about Kubernetes:

The only problem I've solved with Kubernetes was: we had a distributed cron job system (Chronos) that wasn't working reliably (cron jobs would sometimes just not run), and we replaced the system with Kubernetes. Kubernetes' distributed cron was a lot more reliable.

This isn’t a good explanation of why people in general use Kubernetes! But I find reading many specific personal stories like this WAY more helpful than an attempt at cramming “here’s what’s Kubernetes is for” into a few paragraphs.

I want to be clear here that even just explaining your own personal experience isn’t that easy. Technology projects can be messy, and sometimes their goals change in the middle. I started out trying to give an example of why I’ve used Envoy and I realized I would need to think about it for several hours and have a few conversations with old coworkers to explain it coherently so I decided to use a different example.

that’s all for now!

Originally I thought it would be simple to put together these patterns (“there are so many confusing explanations!“) but it was surprisingly hard to articulate exactly what was confusing to me about each explanation in a convincing way.

It’s definitely incomplete, but I’ve already spent two weeks and 3000 words on it so I’ll stop here and I’d love to hear what I’ve missed :)

thanks to Laura, Dan, Kamal, Alyssa, Lindsey, Paul, Ivan, Edith, Hazem, Anton, and John for helping improve this post

translations

here is a translation:

Read the whole story
deebee
21 days ago
reply
America City, America
Share this story
Delete

Mass Market Paperback of Fire & Blood Release

1 Comment

On August 24th Random house officially made the mass market paperback of FIRE AND BLOOD available to the public. You can get your copy at your favorite book seller OR pick up a signed copy at Beastly Books.



LINK to Beastly Books





This message has been brought to you by the minions of Fevre River.





Read the whole story
deebee
22 days ago
reply
The news we’ve all been waiting for!
America City, America
Share this story
Delete

Memo Spike Connector

3 Comments and 4 Shares
Backward-compatible with many existing cables, and can connect directly to phones or tablets if you press them down hard enough.
Read the whole story
deebee
33 days ago
reply
I think this is what R2D2 used to talk to the Death Star
America City, America
Share this story
Delete
1 public comment
alt_text_bot
35 days ago
reply
Backward-compatible with many existing cables, and can connect directly to phones or tablets if you press them down hard enough.

Cafes and Bars in China: Examining the Spatial Routine of Drinking

1 Share
The Cave Bar / Qing Studio. Image © Yilong Zhao The Cave Bar / Qing Studio. Image © Yilong Zhao

Both tea and alcohol in traditional China were similarly aestheticized, and both influenced the language of literature and art. People used to exchange alcohol as a gift in a way that they later would with tea. Today, more and more cities in China have embraced this drinking culture that passed down from generation to generation, and reinterpreted with a new contemporary fashion, which is constantly evolving in the urban cafes and bars.

Read more »

Read the whole story
deebee
45 days ago
reply
America City, America
Share this story
Delete

The Great Depression, Recession and Stagnation in Full Historical Context

1 Comment

While we're on the subject of long-view economic history, let's look at the Great Depression, Great Recession and Great Stagnation in full global historical context.

This chart uses the same (world) economic data as the previous post. I used thin lines to mark the beginning and end of each "Great." Sorry it's so hard to see, but these are just really tiny periods of time. The blue line is technically slowing or even going down a tiny amount in these periods, but not by enough to be visible.

I don't recommend putting things in perspective like this too often. Occasionally seems good.

Twitter Facebook Reddit More



For email filter: florpschmop

Read the whole story
deebee
47 days ago
reply
Send this to every 6000 year old u know
America City, America
Share this story
Delete
Next Page of Stories
